Hobbywing Ezrun MAX5 HV G2 Regler

The ESC uses a special process, coupled with an innovative waterproof design, to increase waterproofing and dust-proofing performance in different climates. It is easy to deal with the harsh conditions containing sediment, ice and snow, water accumulation. Built-in ultra-powerful switch mode BEC with a continuous current of 8A, an instant 25A, and support for 6V/7.4V/8.4V switching, supporting a wide range of powerful and high-voltage servos. Multiple protection functions: battery low voltage protection, ESC and motor overheat protection, signal loss protection, current protection. Supports LED program card, LCD G2 program box, OTA programmer (Note: optional) to set the parameters of the ESC. EZRUN MAX5 HV G2 | Lipo Cells:6-12S Lipo | BEC Output | 6V/7.4V/8.4V adjustable, continuous current 8A (Switch-mode) Motor Limit (Note*) With 8S Lipo: KV≤1200 With 12S Lipo: KV≤800 56118 size motor | Applications:1/5th Buggy, Truck The stable output power, together with an excellent low-speed linearity, ensures the ESC meets various application requirements such as; hard launches, straight-line high-speed, jumps, low speed crawling, etc. 1/5th scale power system Turbo timing technology The ESC is able to support up to 24 degrees of Turbo Timing adjustment. There is an approximate of 18% increase in performance and is recommended to pair with the new HOBBYWING EzRun 56118 SD G2) motors to get the best performance. Note: For non-Hobbywing EzRun 56118 SD G2 motors, Turbo timing cannot be turned on. High protection level, all-weather operation The IP-67 waterproof rating guarantees excellent waterproofing and dustproof protection. The whole power system is able to drive on a variety of surfaces including mud, sand, ice, snow and water without damaging the power unit. Perfect combination with EzRun 56118 SD G2 motor Achieve the perfect compatibility when used together with EzRun 56118 SD G2 motors. Note: Non-Hobbywing EzRun 56118 SD G2 motors cannot realize motor overheat protection Note: Due to the Bluetooth transmission distance, the effective distance is only about 5m! New sensor wire interface, upgraded waterproof protection The new sensor wire interface enhances the ESC protection level and solves waterproof problems faced by traditional interfaces. At the same time, operating temperature is drastically lowered to improve overall stability and reliability of the ESC.Size / Weight:94.5(L) x 59.4(W) x 50.9(H)mm / 428.5g (Included input wires)
